$11.00
Add to Cart
Mini Slide Micro Switch
More than 10 available
Details
Shipping: US-Mainland: free (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
Place of Origin: Guangdong, China (Mainland)
Brand Name: ZING EAR
Model Number: G304-150U00D41
Max. Current: 3A
Max. Voltage: 125/250VAC,48VDC
Operating Temperature: -40℃~+85℃
Protection Level: IP67
Electrical life: 100,000cycles
Mechanical life: 100,000cycles
Rating: 0.1A/125/250VAC 12vdc
Operating force: 150gf max w.o lever
Terminal: Right side PCB connect
Function: SPDT
Post: A type right side posts
Application: Auto Electronics,Air conditioner,communication,tooth brush,toys etc
http://www.greetech-switch.com
Brand Name: ZING EAR
Model Number: G304-150U00D41
Max. Current: 3A
Max. Voltage: 125/250VAC,48VDC
Operating Temperature: -40℃~+85℃
Protection Level: IP67
Electrical life: 100,000cycles
Mechanical life: 100,000cycles
Rating: 0.1A/125/250VAC 12vdc
Operating force: 150gf max w.o lever
Terminal: Right side PCB connect
Function: SPDT
Post: A type right side posts
Application: Auto Electronics,Air conditioner,communication,tooth brush,toys etc
http://www.greetech-switch.com
